Milling Insert: XDKT 070308ER-F40 CTC5240, CTC5240, Solid Carbide N/A Finish,
Item #: 74083205
Brand: Ceratizit
Model #: 50498548
Product Specifications
| Insert Style | XDKT |
| Insert Size Code | 0703 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | CTC5240 |
| Inscribed Circle (Decimal Inch) | 0.1929 |
| Corner Radius (Decimal Inch) | 0.0315 |
| Insert Hand | Right Hand |
| Relief Angle | 15.00 |
| Series | XDKT |
| Coating Process | CVD |
| Hole Diameter (Decimal Inch) | 0.0984 |
| Maximum Depth of Cut (Decimal Inch) | 0.2107 |
| Number Of Cutting Edges | 2 |
| Cutting Edge Effective Length (Decimal Inch) | 0.3071 |
| Insert Shape | Parallelogram |
| Rake | Positive |
| Primary Workpiece Material | Super-Alloys & Titanium |
| Primary Workpiece Material Code | S |
| Iso Code | XDKT 070308ER-F40 CTC5240 |
| Chip Breaker | F40 |
| Coating/Finish | Coated |
| Thickness (Decimal Inch - 4 Decimals) | 0.1252 |
