Sandvik Coromant - External Thread, 1/8" Max Depth of Cut, 5" OAL, Right Hand Indexable Grooving Cutoff Toolholder - 2 Seat Size, 1" Shank Height x 1" Shank Width, TLG 2 Insert Style, TLSR/L Toolholder Style, Series Top Lok
Item #: 73670812
Brand: Sandvik Coromant
Model #: 5753236
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (mm) | 3.18 |
| Maximum Depth of Cut (Decimal Inch) | 0.1250 |
| Overall Length (Inch) | 5 |
| Overall Length (Decimal Inch) | 5.0000 |
| Overall Length (mm) | 127.00 |
| Series | Top Lok |
| Toolholder Style | TLSR/L |
| Insert Compatibility | TLG 2 |
| Shank Height (mm) | 25.40 |
| Shank Height (Inch) | 1 |
| Shank Height (Decimal Inch) | 1.0000 |
| Shank Width/Diameter (mm) | 25.40 |
| Shank Width/Diameter (Inch) | 1 |
| Shank Width/Diameter (Decimal Inch) | 1.0000 |
| Through Coolant | NonThrough Coolant |
| Insert Holding Method | Clamp |
| Back of Bar to Cutting Edge (Decimal Inch) | 5.0000 |
| Head Height (mm) | 25.40 |
| Head Height (Decimal Inch) | 1.0000 |
| Head Length (mm) | 25.40 |
| Head Length (Decimal Inch) | 1.0000 |
| Shank Length (Decimal Inch) | 3.7000 |
| Shank Length (mm) | 93.98 |
| Manufacturers Catalog Number | TLSR-162C |
| Insert Seat Size | 2.0 |
