Milling Insert: APHT 100312SR-33 CTPM240, CTPM240, Solid Carbide N/A Finish,
Item #: 73557209
Brand: Ceratizit
Model #: 51084412
Product Specifications
| Insert Style | APHT |
| Insert Size Code | 1003 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | CTPM240 |
| Inscribed Circle (Decimal Inch) | 0.2618 |
| Corner Radius (Decimal Inch) | 0.0472 |
| Insert Hand | Right Hand |
| Relief Angle | 11.00 |
| Series | APHT |
| Coating Process | PVD |
| Hole Diameter (Decimal Inch) | 0.1102 |
| Maximum Depth of Cut (Decimal Inch) | 0.2904 |
| Number Of Cutting Edges | 1 |
| Cutting Edge Effective Length (Decimal Inch) | 0.4213 |
| Insert Shape | Parallelogram |
| Rake | Positive |
| Primary Workpiece Material | Stainless Steel |
| Primary Workpiece Material Code | M |
| Secondary Workpiece Material | Steel |
| Secondary Workpiece Material Code | P |
| Iso Code | APHT 100312SR-33 CTPM240 |
| Chip Breaker | 33 |
| Coating/Finish | Coated |
| Included Angle Degree | 85 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1378 |
