Kennametal - RCGV35T E Grade KYS25 Ceramic Turning Insert - Uncoated, Round, 1/2" Inscr Circle, 5/16" Thick
Item #: 72783103
Brand: Kennametal
Model #: 4129398
Exact Tooling IR#: 04
Features and Benefits
Ceramic is a highly heat resistant material composed of aluminum oxide and silicon nitride. It is commonly used at high speeds on steel, cast and ductile iron and high temperature alloys.
| Product Specifications | |
|---|---|
| Insert Style | RCGV |
| Insert Size | 35T |
| Material | Ceramic |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Thickness (Inch) | 5/16 |
| Thickness (Decimal Inch) | 0.3125 |
| Manufacturer's Grade | KYS25 |
| Coating | Uncoated |
| Chip Breaker | E |
| ISO Number | RCGX120700E |
| Relief Angle | 7 |
| Manufacturers Catalog Number | RCGV45E |
| Insert Holding Method | Clamp |
| Shape | Round |
