Kennametal - MDHX1004 Grade K110M Carbide Milling Insert - Uncoated, 0.1874" Thick, 1/2" Inscribed Circle
Item #: 72628068
Brand: Kennametal
Model #: 2404943
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | MDHX |
| Insert Size | 1004 |
| Material | Carbide |
| Material Grade | C2/C3 |
| Manufacturer's Grade | K110M |
| Coating | Uncoated |
| Length (Decimal Inch) | 0.4252 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Thickness (Decimal Inch) | 0.1874 |
| Hole Diameter (mm) | 5.45 |
| Hole Diameter (Decimal Inch) | 0.2146 |
| Relief Angle | 15.000 |
| Rake Angle | 15 |
| Shape | Diamond |
| ISO Number | MDHX1004ZDERGD |
