Techniks - 22 to 24mm ER50 Collet - 0.0002" TIR, 2.362" OAL, 2.05" Overall Diam
Item #: 72574858
Brand: Techniks
Model #: 04250-24
Exact Tooling IR#: 04
Features and Benefits
ER collets are used for holding cylindrical shank tools without flats. These collets do not have coolant through capabilities.
| Product Specifications | |
|---|---|
| Type | ER Collet |
| Collet Series | ER50 |
| Size Range (Decimal Inch) | 0.866-0.945 |
| Size Range (mm) | 22.00-24.00 |
| TIR (Decimal Inch) | 0.000200 |
| Overall Length (Decimal Inch) | 2.3620 |
| Overall Diameter (Decimal Inch) | 2.0500 |
| Collet System | ER |
| Number of Pieces | 1 |
| PSC Code | 5136 |
