Metric Blue - M6x1.00 Metric Coarse Hex Socket Drive, Socket Cap Screw - Grade 12.9 Alloy Steel, Metric Blue Finish, Partially Threaded, 80mm Length Under Head
Item #: 71463004
Brand: Metric Blue
Model #: UST176249
Exact Tooling IR#: 04
Features and Benefits
Socket cap head types have large cylindrical heads with recessed hex-shaped drives. They are ideal for applications where limited clearance would not allow the use of wrenches and sockets.
Hex socket drive types have a hex-shaped recess in the head and are driven with hex keys or hex socket bits. The driving surface is protected from external damage and provides six sides of contact surface for added torque.
Alloy steel is the strongest of all steel types. It has high tensile strength and offers excellent resistance to wear, fatigue and galling.
| Product Specifications | |
|---|---|
| System of Measurement | Metric |
| Head Type | Socket Cap |
| Drive Type | Hex Socket |
| Thread Size (mm) | M6x1.00 |
| Length Measurement Type | Length Under Head |
| Length (mm) | 80.00 |
| Material | Alloy Steel |
| Finish/Coating | Metric Blue |
| Full or Partial Threading | Partially Threaded |
| Thread Standard | Metric Coarse |
| Fastener Standard | DIN 912 |
| Hex Key Size (mm) | 5.00 |
| Material Grade | Grade 12.9 |
