Emuge - 1/16-27 NPTF Thread, 4 Flute Standard Pipe Tap - 2-1/8" OAL, 0.69" Thread Length, 5/16" Shank Diam, TiN Finish, Cobalt
Item #: 71163042
Brand: Emuge
Model #: AW181400.5782
Exact Tooling IR#: 04
Features and Benefits
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
| Product Specifications | |
|---|---|
| Thread Size | 1/16-27 |
| Thread Standard | NPTF |
| Material | Cobalt |
| Finish/Coating | TiN |
| Number of Flutes | 4 |
| Overall Length (Decimal Inch) | 2.1250 |
| Overall Length (Inch) | 2-1/8 |
| Thread Length (Decimal Inch) | 0.6900 |
| Shank Diameter (Decimal Inch) | 0.3125 |
| Square Size (Decimal Inch) | 0.2340 |
| Series/List | KEG |
| Chamfer | Modified Bottoming |
