Schneider Electric - 2 Amp, 480Y/277 V, 2 Pole, DIN Rail Mount Miniature Circuit Breaker - Thermal Magnetic Trip, 14-4 AWG, 3 Inch Deep x 3.19 Inch High x 1.42 Inch Wide
Item #: 69669083
Brand: Schneider Electric
Model #: MG24126
Exact Tooling IR#: 04
Features and Benefits
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | Miniature Circuit Breaker |
| Amperage | 2 |
| Number of Poles | 2 |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Lug |
| Mounting Type | DIN Rail Mount |
| Voltage | 480Y/277 V |
| Wire Size (AWG) | 14-4 |
| Overall Depth (Decimal Inch) | 3 |
| Overall Height (Decimal Inch) | 3.1900 |
| Overall Width (Decimal Inch) | 1.4200 |
| For Use With | IEC Supplementary Protection |
