Associated Spring Raymond - 12mm Rod Diam, 100mm Max Stroke, Nitrogen Gas Spring Cylinder - 145mm Body Length, 245mm OAL, 340 Lb Full Stroke Spring Force, 87 psi Initial Charge
Item #: 69139814
Brand: Associated Spring Raymond
Model #: EPS2 24-100-RE
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Initial Charge Pressure (psi) | 87 |
| Initial Charge Pressure (bar) | 6 |
| Body Length (mm) | 145 |
| Body Length (Decimal Inch) | 5.7087 |
| Spring Force Initial (N) | 850 |
| Spring Force Initial (lbf) | 191 |
| Spring Force Full Stroke (N) | 1512 |
| Spring Force Full Stroke (lbf) | 340 |
| Rod Diameter (mm) | 12 |
| Rod Diameter (Decimal Inch) | 0.4724 |
| Overall Length (mm) | 245 |
| Overall Length (Decimal Inch) | 9.6457 |
| Maximum Stroke (mm) | 100 |
| Maximum Stroke (Decimal Inch) | 3.9370 |
