Associated Spring Raymond - 12mm Rod Diam, 80mm Max Stroke, Nitrogen Gas Spring Cylinder - 125mm Body Length, 205mm OAL, 90 Lb Full Stroke Spring Force, 87 psi Initial Charge
Item #: 69139780
Brand: Associated Spring Raymond
Model #: EPS2 24-080-GR
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Initial Charge Pressure (psi) | 87 |
| Initial Charge Pressure (bar) | 6 |
| Body Length (mm) | 125 |
| Body Length (Decimal Inch) | 4.9213 |
| Spring Force Initial (N) | 231 |
| Spring Force Initial (lbf) | 52 |
| Spring Force Full Stroke (N) | 400 |
| Spring Force Full Stroke (lbf) | 90 |
| Rod Diameter (mm) | 12 |
| Rod Diameter (Decimal Inch) | 0.4724 |
| Overall Length (mm) | 205 |
| Overall Length (Decimal Inch) | 8.0709 |
| Maximum Stroke (mm) | 80 |
| Maximum Stroke (Decimal Inch) | 3.1496 |
