Niagara Cutter - Ball End Mills Mill Diameter (Inch): 0.750 Mill Diameter (Decimal Inch): 0.7500
Item #: 16451742
Brand: Niagara Cutter
Model #: 10008106
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Ball End Mills; Mill Diameter (Inch): 0.750 ; Mill Diameter (Decimal Inch): 0.7500 ; Number of Flutes: 6 ; Length of Cut (Inch): 1.750 ; Material: Solid Carbide ; Overall Length (Inch): 4
| Mill Diameter (Inch) | 0.750 |
| Mill Diameter (Decimal Inch) | 0.7500 |
| Number of Flutes | 6 |
| Length of Cut (Inch) | 1.750 |
| Material | Solid Carbide |
| Overall Length (Inch) | 4 |
| Shank Diameter (Inch) | 3/4 |
| Finish/Coating | HTA |
| Single or Double End | Single |
| Helix Angle | 38 |
| Variable Index | Yes |
| Variable Helix | Yes |
| Nose Radius (Decimal Inch) | 0.3750 |
| Flute Type | Helical |
| Undercutting | No |
| Length Type | Short |
| Series/List | SB638 |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
