Kitagawa - 3 Jaws, 15" Chuck Diam, Plain Back Mount, Drawbar, Hydraulic Power Lathe Chuck - 55,860 Lb Force per Jaw, 1.5mm x 60 Serrated Jaw Interface, 72mm to 381mm Jaw Capacity, 3,040 RPM, Steel Body
Item #: 67296376
Brand: Kitagawa
Model #: N15
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Chuck Diameter (mm) | 381.00 |
| Chuck Diameter (Inch) | 15 |
| Number of Jaws | 3 |
| Mount | Plain Back |
| Chuck Actuation Style | Drawbar |
| Operation Type | Hydraulic |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Minimum Jaw Capacity (mm) | 72.00 |
| Maximum Jaw Capacity (mm) | 381.00 |
| Jaw Stroke Diameter (mm) | 16.00 |
| Piston Stroke Length (Decimal Inch) | 1.3780 |
| Maximum Drawbar Pulling Force (kN) | 82.00 |
| Maximum Static Gripping Force (kN) | 249.00 |
| Force Per Jaw (Lb.) | 55860.00 |
| Moment of Inertia (kgf/sq m) | 1.8000 |
| Maximum RPM | 3040 |
| Body Material | Steel |
| Power Cylinder Compatibility | Y2035R |
| Includes | Chuck Assembled w/ Adapter; Chuck Mounting Bolts; Draw Nut Wrench; Jaw Mounting Bolts w/ Wrench; Soft Top Jaws; T-Nuts |
