Press Fit Headless Drill Bushing: HM, 14.5″ ID Steel
Item #: 63735807
Brand: Boneham
Model #: AM00000039
Product Specifications
| Installation Method | Press Fit |
| Bushing Industry Code | HM |
| Inside Diameter (Wire) | 14.5 |
| Inside Diameter (mm) | 14.50 |
| Inside Diameter (Decimal Inch) | 14.500 |
| Body Outside Diameter (mm) | 22.00 |
| Overall Bushing Length (mm) | 16.00 |
| Bushing Material | Steel |
| Renewable Bushing | No |
| Hardness | 60 to 65 HRC |
| Inside Diameter Tolerance | +0.006/+0.017 mm |
| Counterbored | No |
| Standards | ANSI |
