Guhring - 5/16-24 UNF, 3 Flute, Bright Finish, Cobalt Spiral Point Tap - Plug Chamfer, Right Hand Thread, 2.72" OAL, 0.71" Thread Length, 0.318" Shank Diam, 2B Class of Fit, Series 3914
Item #: 63266845
Brand: Guhring
Model #: 9039140079380
Exact Tooling IR#: 04
Features and Benefits
Plug chamfers are the most commonly used chamfer and are designed for efficiently threading through and blind holes. They have 3 to 5 threads.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
| Product Specifications | |
|---|---|
| Thread Size (Inch) | 5/16-24 |
| Number of Flutes | 3 |
| Chamfer | Plug |
| Class of Fit | 2B |
| Finish/Coating | Bright |
| Material | Cobalt |
| Through Coolant | NonThrough Coolant |
| Thread Direction | Right Hand |
| Overall Length (Decimal Inch) | 2.7200 |
| Oversize | No |
| Thread Standard | UNF |
| Thread Length (Decimal Inch) | 0.7100 |
| Series/List | 3914 |
| Shank Diameter (Decimal Inch) | 0.3180 |
| Square Size (Decimal Inch) | 0.2380 |
| Material Application | Alloyed Steel; Unalloyed Steel |
