Electro Hardware - #4-40, 1" OAL, 3/16" Across Flats, Nylon Hex Male/Female Circuit Board Standoffs - 1/4" Thread Depth, 1" Body Length, Uncoated
Item #: 63211288
Brand: Electro Hardware
Model #: 1329M19F16440
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with male/female threads have one externally threaded end and one internally threaded end. The female end accepts male fasteners or other standoffs.
Nylon is a lightweight, nonconductive material that is resistant to impact, wear and abrasion. It is ideal for electrical applications or where corrosion is a concern.
| Product Specifications | |
|---|---|
| Thread Type | Male/Female |
| Material | Nylon |
| System of Measurement | Inch |
| Body Shape | Hex |
| Overall Length (Inch) | 1 |
| Overall Length (Decimal Inch) | 1.0000 |
| Thread Size | #4-40 |
| Width Across Flats (Decimal Inch) | 0.1875 |
| Width Across Flats (Inch) | 3/16 |
| Finish/Coating | Uncoated |
| Body Length (Inch) | 1 |
| Body Length (Decimal Inch) | 1.0000 |
| Thread Length (Inch) | 3/16 |
| Thread Depth (Inch) | 1/4 |
| Tensile Strength (psi) | 16500.00 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Material Grade | Grade 101 |
| Fastener Standard | MIL-P-17091B |
