Iscar - 1.2598" Blade Height, 0.311" Blade Width, 4.3504" OAL, Left Hand Cut, Single End Indexable Cut-Off Blade - TGFH Blade, Tang-Grip Series
Item #: 63111686
Brand: Iscar
Model #: 2301878
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Single or Double End | Single |
| Cutting Direction | Left Hand |
| Blade Height (mm) | 32.00 |
| Blade Height (Decimal Inch) | 1.2598 |
| Blade Width (mm) | 7.90 |
| Blade Width (Decimal Inch) | 0.3110 |
| Blade Overall Length (mm) | 110.50 |
| Blade Overall Length (Decimal Inch) | 4.3504 |
| Blade Style | TGFH |
| Insert Style | TAG N-A; TAG N-C/W/M; TAG N-J/JS/JT; TAG N-LF; TAG N-MF; TAG N-UT; TAG R/L-C; TAG R/L-J/JS |
| Insert Width (mm) | 2.80 |
| Insert Width (Decimal Inch) | 0.1102 |
| Series | Tang-Grip |
| Tool Block/Toolholder Style | HSK A-WH-TBK-R/L; SGTBF; SGTBK; SGTBU/SGTBN; UBHCR/L |
| Insert Holding Method | Self Grip |
| Maximum Workpiece Diameter (Decimal Inch) | 1.6535 |
| Cutting Height (mm) | 24.80 |
| Cutting Height (Decimal Inch) | 0.9764 |
| Minimum Insert Width (mm) | 2.80 |
| Minimum Insert Width (Decimal Inch) | 0.1102 |
| Maximum Insert Width (mm) | 3.50 |
| Maximum Insert Width (Decimal Inch) | 0.1378 |
| Complete Insert Compatibility | TAG L3J-15D; TAG L3J-6D; TAG L3JS-6D; TAG N3A; TAG N3LF; TAG N3MF; TAG N3UT; TAG R3J-6D; TAG R3JS-6D |
| Complete Tool Block/Toolholder Style Compatibility | HSK A100WH-TBK-32L; HSK A63WH-TBK-32L; HSK A63WH-TBK-32R; SGTBF 25.4-A; SGTBF 31.7-A; SGTBK 32-9; SGTBU 19-6G; SGTBU 25.4-6G; SGTBU 25.4C-6; SGTBU 31.8-6G; SGTBU 38.1-6G; UBHCL 25.4-32; UBHCR 25.4-32 |
