Parker - 3/16" ID x 5/16" OD, 1/16" Wall Thickness, 25' Long, PTFE Tube - Blue Stripe, 222 Max psi, -100 to 500°F
Item #: 61570115
Brand: Parker
Model #: 10103120626TS25
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Inside Diameter (Decimal Inch) | 0.1875 |
| Inside Diameter (Inch) | 3/16 |
| Outside Diameter (Decimal Inch) | 0.3125 |
| Outside Diameter (Inch) | 5/16 |
| Wall Thickness (Decimal Inch) | 0.0620 |
| Material | PTFE |
| Maximum Working Pressure (psi) | 222 |
| Color | Blue Stripe |
| Standard Coil Length (Feet) | 25 |
| Length (Ft) | 25 |
| Minimum Temperature (F) | -100 |
| Maximum Temperature (F) | 500 |
