Associated Spring Raymond - 7/16" Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.083" High, 0.033" Thick
Item #: 61411377
Brand: Associated Spring Raymond
Model #: BC0875033S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 7/16 |
| Bolt Size (mm) | 11.11 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 0.84 |
| Thickness (Decimal Inch) | 0.0330 |
| Overall Height (mm) | 2.11 |
| Overall Height (Decimal Inch) | 0.0830 |
| Deflection (Decimal Inch) | 0.0370 |
| Deflection (mm) | 0.94 |
| Minimum Inside Diameter (Decimal Inch) | 0.4420 |
| Minimum Inside Diameter (mm) | 11.23 |
| Maximum Outside Diameter (Decimal Inch) | 0.8750 |
| Maximum Outside Diameter (mm) | 22.23 |
| Load at Flat (Lb.) | 233.00 |
| Load at Flat (N) | 1036.44 |
| Minimum Load at Deflection (Lb.) | 119.00 |
| Minimum Load at Deflection (N) | 529.34 |
| Maximum Load at Deflection (Lb.) | 178.40 |
| Maximum Load at Deflection (N) | 793.56 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 7/16 |
