Associated Spring Raymond - 3/8" Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.086" High, 0.043" Thick
Item #: 61411328
Brand: Associated Spring Raymond
Model #: BC0750043S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 3/8 |
| Bolt Size (mm) | 9.53 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 1.09 |
| Thickness (Decimal Inch) | 0.0430 |
| Overall Height (mm) | 2.18 |
| Overall Height (Decimal Inch) | 0.0860 |
| Deflection (Decimal Inch) | 0.0320 |
| Deflection (mm) | 0.81 |
| Minimum Inside Diameter (Decimal Inch) | 0.3800 |
| Minimum Inside Diameter (mm) | 9.65 |
| Maximum Outside Diameter (Decimal Inch) | 0.7500 |
| Maximum Outside Diameter (mm) | 19.05 |
| Load at Flat (Lb.) | 594.00 |
| Load at Flat (N) | 2642.24 |
| Minimum Load at Deflection (Lb.) | 297.60 |
| Minimum Load at Deflection (N) | 1323.79 |
| Maximum Load at Deflection (Lb.) | 446.40 |
| Maximum Load at Deflection (N) | 1985.69 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 3/8 |
