Associated Spring Raymond - 3/8" Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.073" High, 0.03" Thick
Item #: 61411310
Brand: Associated Spring Raymond
Model #: BC0750030S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 3/8 |
| Bolt Size (mm) | 9.53 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 0.76 |
| Thickness (Decimal Inch) | 0.0300 |
| Overall Height (mm) | 1.85 |
| Overall Height (Decimal Inch) | 0.0730 |
| Deflection (Decimal Inch) | 0.0320 |
| Deflection (mm) | 0.81 |
| Minimum Inside Diameter (Decimal Inch) | 0.3800 |
| Minimum Inside Diameter (mm) | 9.65 |
| Maximum Outside Diameter (Decimal Inch) | 0.7500 |
| Maximum Outside Diameter (mm) | 19.05 |
| Load at Flat (Lb.) | 202.00 |
| Load at Flat (N) | 898.54 |
| Minimum Load at Deflection (Lb.) | 103.00 |
| Minimum Load at Deflection (N) | 458.17 |
| Maximum Load at Deflection (Lb.) | 154.50 |
| Maximum Load at Deflection (N) | 687.25 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 3/8 |
