Associated Spring Raymond - 5/16" Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.058" High, 0.022" Thick
Item #: 61411252
Brand: Associated Spring Raymond
Model #: BC0625022S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 5/16 |
| Bolt Size (mm) | 7.94 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 0.56 |
| Thickness (Decimal Inch) | 0.0220 |
| Overall Height (mm) | 1.47 |
| Overall Height (Decimal Inch) | 0.0580 |
| Deflection (Decimal Inch) | 0.0270 |
| Deflection (mm) | 0.69 |
| Minimum Inside Diameter (Decimal Inch) | 0.3170 |
| Minimum Inside Diameter (mm) | 8.05 |
| Maximum Outside Diameter (Decimal Inch) | 0.6250 |
| Maximum Outside Diameter (mm) | 15.88 |
| Load at Flat (Lb.) | 92.00 |
| Load at Flat (N) | 409.24 |
| Minimum Load at Deflection (Lb.) | 52.50 |
| Minimum Load at Deflection (N) | 233.53 |
| Maximum Load at Deflection (Lb.) | 78.70 |
| Maximum Load at Deflection (N) | 350.08 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 5/16 |
