Cleveland - #43 135° Parabolic Flute Cobalt Screw Machine Drill Bit
Item #: 57613143
Brand: Cleveland
Model #: C14430
Features and Benefits
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Parabolic flutes have a wider flute shape for increased chip flow.
| Product Specifications | |
|---|---|
| Drill Bit Size (Decimal Inch) | 0.0890 |
| Drill Bit Size (Wire) | #43 |
| Drill Point Angle | 135 |
| Drill Bit Material | Cobalt |
| Drill Bit Finish/Coating | TiN |
| Flute Type | Parabolic |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Flute Length (mm) | 19.05 |
| Flute Length (Decimal Inch) | 0.7500 |
| Overall Length (mm) | 44.45 |
| Overall Length (Decimal Inch) | 1.7500 |
| Point Type | Standard |
| Shank Diameter (mm) | 2.26 |
| Shank Diameter (Decimal Inch) | 0.0890 |
| Specification Designation | ANSI |
| Shank Length (mm) | 25.40 |
| Shank Length (Decimal Inch) | 1.0000 |
| Threaded Shank | No |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0005 |
| Drill Tip Finish/Coating | None |
| Drill Bit Grade | High Performance |
| Material Grade | M42 |
| Series/List | 2175 |
| Length Type | Regular |
