Kennametal - External Thread, 170.25mm OAL, Left Hand Indexable Grooving Cutoff Toolholder - 32mm Shank Height x 32mm Shank Width, KGME Toolholder Style, Series A4
Item #: 58466624
Brand: Kennametal
Model #: 1621086
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Hand of Holder | Left Hand |
| Overall Length (Decimal Inch) | 6.7028 |
| Overall Length (mm) | 170.25 |
| Series | A4 |
| Toolholder Style | KGME |
| Shank Height (mm) | 32.00 |
| Shank Height (Decimal Inch) | 1.2598 |
| Shank Width/Diameter (mm) | 32.00 |
| Shank Width/Diameter (Decimal Inch) | 1.2598 |
| Through Coolant | NonThrough Coolant |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.6830 |
| Shank Length (Decimal Inch) | 5.7185 |
| Shank Length (mm) | 145.25 |
