Kennametal - 16mm Cut Diam, 8mm Max Depth of Cut, 16mm Shank Diam, 140mm OAL, Indexable Ball Nose End Mill - 35mm Head Length, Straight Shank, KDMB Toolholder, KDMB 16.. Insert
Item #: 58456708
Brand: Kennametal
Model #: 1918678
Exact Tooling IR#: 04
Features and Benefits
Straight shanks are used for general purpose machining and commonly have a larger diameter than taper shanks.
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 16.00 |
| Cutting Diameter (Decimal Inch) | 0.6300 |
| Maximum Depth of Cut (mm) | 8.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3150 |
| Shank Type | Straight Shank |
| Shank Diameter (mm) | 16.00 |
| Shank Diameter (Decimal Inch) | 0.6299 |
| Number of Ball Nose Inserts Used on Toolholder | 1 |
| Insert Style | KDMB 16.. |
| Toolholder Style | KDMB |
| Series | KDMB |
| Overall Length (mm) | 140.00 |
| Overall Length (Decimal Inch) | 5.5118 |
| Insert Holding Method | Screw |
| Through Coolant | NonThrough Coolant |
| Weldon Flat | No |
| Tapered Neck | No |
| Number of Flutes | 2 |
| Head Length (mm) | 35.00 |
| Head Length (Decimal Inch) | 1.3780 |
| Neck Diameter (Decimal Inch) | 0.5512 |
| Maximum RPM | 40000 |
