Kennametal - 32mm Cut Diam, 16mm Max Depth of Cut, 32mm Shank Diam, 210mm OAL, Indexable Ball Nose End Mill - 80mm Head Length, Straight Shank, KDMB Toolholder, KDMB 32.. Insert
Item #: 58456658
Brand: Kennametal
Model #: 1918685
Exact Tooling IR#: 04
Features and Benefits
Straight shanks are used for general purpose machining and commonly have a larger diameter than taper shanks.
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 32.00 |
| Cutting Diameter (Decimal Inch) | 1.2598 |
| Maximum Depth of Cut (mm) | 16.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.6299 |
| Shank Type | Straight Shank |
| Shank Diameter (mm) | 32.00 |
| Shank Diameter (Decimal Inch) | 1.2598 |
| Number of Ball Nose Inserts Used on Toolholder | 1 |
| Insert Style | KDMB 32.. |
| Toolholder Style | KDMB |
| Series | KDMB |
| Overall Length (mm) | 210.00 |
| Overall Length (Decimal Inch) | 8.2677 |
| Insert Holding Method | Screw |
| Through Coolant | NonThrough Coolant |
| Weldon Flat | No |
| Tapered Neck | No |
| Number of Flutes | 2 |
| Head Length (mm) | 80.00 |
| Head Length (Decimal Inch) | 3.1496 |
| Neck Diameter (Decimal Inch) | 1.1260 |
| Maximum RPM | 40000 |
