Seco - Arbor Hole Connection, 0.122" Cutting Width, 3/4" Depth of Cut, 3" Cutter Diam, 3 Tooth Indexable Slotting Cutter - 1-1/4" Shank Diam, R335.10 Toolholder, 150.10-3N Insert, Right Hand Cutting Direction
Item #: 57058232
Brand: Seco
Model #: 54831
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (Decimal Inch) | 0.1220 |
| Maximum Depth of Cut (Decimal Inch) | 0.7500 |
| Cutter Diameter (Decimal Inch) | 3.0000 |
| Shank Diameter (Decimal Inch) | 1.2500 |
| Number of Teeth | 3 |
| Toolholder Style | R335.10 |
| Series | R335.10 |
| Insert Style | 150.10-3N |
| Staggered Tooth | No |
| Number of Cutter Inserts | 6 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Maximum RPM | 3500 |
| Minimum Cutting Width (Decimal Inch) | 0.1220 |
| Maximum Cutting Width (Decimal Inch) | 0.1220 |
| Radius | No |
| Rake | Positive |
| Weldon Flat | Yes |
| Complete Insert Compatibility1 | 150.10-3N-16; 150.10-3N-14; 150.10-3N-12 |
