Cleveland - 7/32" 118° Spiral Flute Carbide-Tipped Taper Length Drill Bit
Item #: 68292309
Brand: Cleveland
Model #: C49052
Features and Benefits
Carbide tips cuts faster than high speed steel. It is commonly used on ferrous and nonferrous metals including cast iron, steel and steel alloy.
Gold provides a polished finish on a cobalt or high speed steel tool. It is commonly used on aluminum alloy, titanium and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (Inch) | 7/32 |
| Drill Bit Size (Decimal Inch) | 0.2188 |
| Drill Point Angle | 118 |
| Drill Bit Material | Carbide-Tipped |
| Drill Bit Finish/Coating | Gold Finish |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Tanged |
| Through Coolant | No |
| Point Type | Standard |
| Flute Length (Decimal Inch) | 3.6250 |
| Flute Length (mm) | 92.08 |
| Overall Length (mm) | 152.40 |
| Overall Length (Decimal Inch) | 6.0000 |
| Spiral Type | Regular Spiral |
| Shank Diameter (mm) | 5.56 |
| Shank Diameter (Decimal Inch) | 0.2188 |
| Shank Length (mm) | 60 |
| Shank Length (Decimal Inch) | 2.3748 |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0007 |
| Web Thinning | Web-Thinned |
| Series/List | 2745 |
