Bilz - 3mm to 26mm Capacity, 120mm Projection, HSK100A Taper Shank, ER40 Collet Chuck - 0.003mm TIR, Through-Spindle & DIN Flange Coolant
Item #: 56873425
Brand: Bilz
Model #: 66661128M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Collet System | ER |
| Collet Series | ER40 |
| Shank Type | Taper Shank |
| Taper Size | HSK100A |
| Projection (mm) | 120.00 |
| Through Coolant | Yes |
| Minimum Collet Capacity (mm) | 3.00 |
| Maximum Collet Capacity (mm) | 26.00 |
| Nose Diameter (mm) | 63.00 |
| PSC Code | 5136 |
| Balanced to (RPM) | 20000 |
| TIR (mm) | 0.0030 |
| Coolant Type | Through-Spindle & DIN Flange |
| Collet Nut Diameter (mm) | 63.00 |
