DORMER - 10.5mm 130° Spiral Flute High Speed Steel Screw Machine Drill Bit
Item #: 79769857
Brand: DORMER
Model #: 0038642
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications on both ferrous and nonferrous materials.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Spiral flutes are constructed of a higher flute angle to remove chips easier.
| Product Specifications | |
|---|---|
| Drill Bit Size (Decimal Inch) | 0.4134 |
| Drill Bit Size (mm) | 10.50 |
| Drill Point Angle | 130 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | TiN |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Flute Length (mm) | 43.00 |
| Overall Length (mm) | 89.00 |
| Point Type | ADX |
| Shank Diameter (Decimal Inch) | 0.4134 |
| Specification Designation | DIN |
| Spiral Type | Regular Spiral |
| Shank Length (mm) | 46.00 |
| Threaded Shank | No |
| Web Configuration | Parallel |
| Specification Number | DIN 1897 |
| Web Thinning | Web-Thinned |
| Drill Bit Grade | Heavy Duty |
| Series/List | A520 |
