HAIMER - C Style, BT30 Taper, M12x1.75 Thread, 45° Angle Radius, High Torque Retention Knob - 1.693" OAL, 0.4331" Knob Diam, 0.7087" Flange Thickness, 0.9055" from Knob to Flange, 0.4921" Pilot Diam, 0.0394" Coolant Hole, Through Coolant
Item #: 55736458
Brand: HAIMER
Model #: 88.600.30
Exact Tooling IR#: 04
Features and Benefits
High torque knobs improve the fit of the toolholder with the spindle. They prevent the small end of the toolholder from expanding by using a precision pilot and place the force of the threads into a deeper cross-section of material in the toolholder.
| Product Specifications | |
|---|---|
| Type | High Torque |
| Taper Size | BT30 |
| Thread Size | M12x1.75 |
| Angle Radius | 45.00 |
| Knob Diameter (Decimal Inch) | 0.4331 |
| Through Coolant | Yes |
| Style | C |
| Neck Diameter (Decimal Inch) | 0.2756 |
| Pilot Diameter (Decimal Inch) | 0.4921 |
| Overall Length (Decimal Inch) | 1.6930 |
| Knob to Flange Length (Decimal Inch) | 0.9055 |
| Flange Thickness (Decimal Inch) | 0.7087 |
| Coolant Hole Diameter (Decimal Inch) | 0.0394 |
