HAIMER - C Style, BT50 Taper, M24x3 Thread, 45° Angle Radius, High Torque Retention Knob - 3.346" OAL, 0.9055" Knob Diam, 1.3779" Flange Thickness, 1.7716" from Knob to Flange, 0.9843" Pilot Diam, 0.2362" Coolant Hole, Through Coolant
Item #: 55736417
Brand: HAIMER
Model #: 88.603.50
Exact Tooling IR#: 04
Features and Benefits
High torque knobs improve the fit of the toolholder with the spindle. They prevent the small end of the toolholder from expanding by using a precision pilot and place the force of the threads into a deeper cross-section of material in the toolholder.
| Product Specifications | |
|---|---|
| Type | High Torque |
| Taper Size | BT50 |
| Thread Size | M24x3 |
| Angle Radius | 45.00 |
| Knob Diameter (Decimal Inch) | 0.9055 |
| Through Coolant | Yes |
| Style | C |
| Neck Diameter (Decimal Inch) | 0.6693 |
| Pilot Diameter (Decimal Inch) | 0.9843 |
| Overall Length (Decimal Inch) | 3.3460 |
| Knob to Flange Length (Decimal Inch) | 1.7716 |
| Flange Thickness (Decimal Inch) | 1.3779 |
| Coolant Hole Diameter (Decimal Inch) | 0.2362 |
