Omron - Standard Electromechanical Screw General Purpose Relay - 25 Amp at 220 VAC, DPST, 12 VDC, 68.5mm Wide x 49mm High x 34.5mm Deep
Item #: 54048665
Brand: Omron
Model #: G7L2ABUBJCBDC12
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Relay Form | Electromechanical |
| Coil Voltage | 12 VDC |
| Terminal Type | Screw |
| Contact Form | DPST |
| Amperage | 25 @ 220 VAC |
| Maximum Power Rating (W) | 1.90 |
| Base Shape | Standard |
| Overall Height (mm) | 49 |
| Overall Height (Decimal Inch) | 1.9300 |
| Overall Width (mm) | 68-1/2 |
| Overall Width (Decimal Inch) | 2.7000 |
| Overall Depth (mm) | 34-1/2 |
| Overall Depth (Decimal Inch) | 1.3600 |
| Standards Met | CSA Certified; IEC; RoHS Compliant; TUV; UL Listed |
