Sumitomo - SPMT322 ELU Grade AC700G Carbide Turning Insert - TiC Finish, 90° Square, 3/8" Inscr Circle, 1/8" Thick, 1/32" Corner Radius
Item #: 53985727
Brand: Sumitomo
Model #: 19DYBUR
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | SPMT |
| Insert Size | 322 |
| Material | Carbide |
| Length (Inch) | 3/8 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Inscribed Circle (Inch) | 3/8 |
| Thickness (Inch) | 1/8 |
| Thickness (Decimal Inch) | 0.1250 |
| Corner Radius (Inch) | 1/32 |
| Corner Radius (Decimal Inch) | 0.0313 |
| Manufacturer's Grade | AC700G |
| Coating | TiC |
| Chip Breaker | ELU |
| Hole Diameter (Decimal Inch) | 0.1300 |
| Rake | Negative |
| Rake Angle | 10 |
| Relief Angle | 11 |
| Coating Process | CVD |
| Included Angle | 90 |
| Insert Holding Method | Screw |
| Shape | Square |
