Seco - 2503005X4GKL Grade TGH1050, 0.04" Cutting Width Carbide Grooving Insert - 0.169" Max Depth of Cut, Left Hand, 0.05mm Corner Radius
Item #: 52815453
Brand: Seco
Model #: 43367
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | X4GKL |
| Insert Size | 2503005 |
| Material | Carbide |
| Cutting Width (mm) | 1.00 |
| Cutting Width (Inch) | 0.0400 |
| Cutting Width (Decimal Inch) | 0.0400 |
| Maximum Depth of Cut (mm) | 4.30 |
| Maximum Depth of Cut (Inch) | 0.1690 |
| Maximum Depth of Cut (Decimal Inch) | 0.1690 |
| Manufacturer's Grade | TGH1050 |
| Insert Hand | Left Hand |
| Cutting Height (mm) | 20.40 |
| Cutting Height (Inch) | 0.8030 |
| Cutting Height (Decimal Inch) | 0.8030 |
| Lead Angle | 0 |
| Multi-Use Tool | Yes |
| Minimum Corner Radius (Decimal Inch) | 0.0008 |
| Maximum Corner Radius (Decimal Inch) | 0.0031 |
| Corner Radius (mm) | 0.05 |
| Series | X4 |
