Iscar - External Thread, 1-1/2" Max Depth of Cut, 0.236" Min Groove Width, 6" OAL, Right Hand Indexable Grooving Cutoff Toolholder - 1" Shank Height x 1" Shank Width, DGN 6008/GRIP 60.. Insert Style, DGT Toolholder Style, Series Do-Grip
Item #: 52701992
Brand: Iscar
Model #: 2301377
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 1.5000 |
| Minimum Groove Width (Decimal Inch) | 0.2360 |
| Maximum Groove Width (Decimal Inch) | 0.2360 |
| Overall Length (Decimal Inch) | 6.0000 |
| Series | Do-Grip |
| Toolholder Style | DGT |
| Insert Compatibility | DGN 6008; GRIP 60.. |
| Shank Height (Decimal Inch) | 1.0000 |
| Shank Width/Diameter (Decimal Inch) | 1.0000 |
| Through Coolant | NonThrough Coolant |
| Insert Holding Method | Clamp |
| Full Radius Insert | No |
| Complete Insert Compatibility | DGN 6008UT; GRIP 6005Y; GRIP 6008Y; GRIP 6030Y |
