KIPP - M10x1, 15mm Thread Length, 5mm Plunger Diam, Locking Pin Knob Handle Indexing Plunger - Plunger Style F, 17mm Body Length, 37mm OAL, Stainless Steel
Item #: 52216090
Brand: KIPP
Model #: K0341.12105
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M10x1 |
| Thread Length (mm) | 15.00 |
| Thread Length (Decimal Inch) | 0.5906 |
| Plunger Diameter (mm) | 5.00 |
| Plunger Diameter (Decimal Inch) | 0.1969 |
| Body Length (mm) | 17.00 |
| Body Length (Decimal Inch) | 0.6693 |
| Plunger Type | Non-Hardened Locking Pin |
| Indexing Plunger Style Code | F |
| Lock Nut | Yes |
| Plunger Projection (mm) | 5.00 |
| Plunger Projection (Decimal Inch) | 0.1969 |
| Initial End Force (N) | 5.00 |
| Final End Force (N) | 12.00 |
| Distance Across Nut Flats (mm) | 13.00 |
| Distance Across Nut Flats (Decimal Inch) | 0.5118 |
| Nut Height (mm) | 7.00 |
| Nut Height (Decimal Inch) | 0.2756 |
| Overall Length (mm) | 37.00 |
| Overall Length (Decimal Inch) | 1.4567 |
| Stud Thread Size | M4 |
| Tolerance (mm) | -0.04; -0.02 |
| Material | Stainless Steel |
| Finish/Coating | Natural |
