Corner Radius End Mill: 5/16″ Dia, 5/8″ LOC, 0.015″ Radius, 4 Flutes 2-3/16″ OAL, 5/16″ Shank Dia, Variable ° Helix, AlTiN Coated, Corner Radius End
Item #: 52175338
Brand: HAIMER
Model #: F1004NNL5/16ZR.
Product Specifications
| Mill Diameter (Decimal Inch) | 0.3125; 0.3125 in |
| Mill Diameter (Inch) | 5/16; 0.3125 in |
| End Type | Corner Radius |
| Corner Radius (Decimal Inch) | 0.0150 |
| Number of Flutes | 4 |
| Finish/Coating | AlTiN |
| Length of Cut (Decimal Inch) | 0.6250 |
| Length of Cut (Inch) | 5/8 |
| Shank Diameter (Inch) | 5/16; 5/16 in |
| Overall Length (Inch) | 2-3/16 |
| Extended Reach | Yes |
| Helix Angle | Variable |
| Reach Length (Decimal Inch) | 0.81 in |
| Reach Length (Inch) | 13/16; 0.81 in |
| Neck Diameter (Decimal Inch) | 0.296 in; 0.2960 |
| Material Grade | Submicron |
| Single or Double End | Single |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Shank Diameter Tolerance (Decimal Inch) | 5/16 in |
| Overall Length Tolerance (Decimal Inch) | +0.0020 to -0.0020 in; +0.002/-0.002 |
| Overall Length Tolerance (mm) | +0.0020 to -0.0020 in |
