Corner Chamfer End Mill: 0.25″ Dia, 0.5″ LOC, 4 Flute, 0.008″ Chamfer Width, Solid Carbide 2″ OAL, 1/4″ Shank Dia, 35 ° Helix, AlTiN Coated, Centercutting
Item #: 52175296
Brand: HAIMER
Model #: F1304NNL1/4ZCAA
Product Specifications
| Mill Diameter (Inch) | 1/4 |
| Mill Diameter (mm) | 0.25 in |
| Mill Diameter (Decimal Inch) | 0.25 in; 0.2500 |
| Number of Flutes | 4 |
| Length of Cut (Inch) | 1/2 |
| Length of Cut (Decimal Inch) | 0.5000 |
| Shank Diameter (Inch) | 1/4 in; 1/4 |
| Shank Diameter (mm) | 1/4 in |
| Shank Diameter (Decimal Inch) | 1/4 in |
| Material | Solid Carbide |
| Finish/Coating | AlTiN |
| Overall Length (mm) | 2.0 in; 2 in |
| Overall Length (Inch) | 2.0 in; 2; 2 in |
| Centercutting | Yes; Center Cutting |
| Helix Angle | 35.00 |
| Extended Reach | Yes |
| Chamfer Width (Decimal Inch) | 0.0080; 0.0080 in |
| Chamfer Angle | 45 |
| Material Grade | Submicron |
| Single or Double End | Single |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Overall Length Tolerance (Decimal Inch) | +0.002 to -0.002 in; +0.002/-0.002 |
| TIR Maximum (Decimal Inch) | 0.0002 |
| Reach Length (Inch) | 5/8 |
| Overall Length (Decimal Inch) | 2.0 in; 2 in; 2.0000 |
