Kyocera - KGBA, External, Left Hand, 0.217" Max Depth of Cut, 0.013 to 0.189" Groove Width, Indexable Grooving Tool Holder - GBA43R/L.. Insert Compatibility, 3/4" Shank Height, 3/4" Shank Width, 5" OAL
Item #: 50415348
Brand: Kyocera
Model #: 8606039
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.2170 |
| Minimum Groove Width (Decimal Inch) | 0.0130 |
| Maximum Groove Width (Decimal Inch) | 0.1890 |
| Overall Length (Decimal Inch) | 5.0000 |
| Toolholder Style | KGBA |
| Insert Compatibility | GBA43R/L.. |
| Shank Height (Decimal Inch) | 0.7500 |
| Shank Width/Diameter (Decimal Inch) | 0.7500 |
| Series | KGBA |
| Through Coolant | Non Coolant Through |
| Multi-Use Tool | No |
| Insert Holding Method | Clamp |
| Maximum Hole Depth (Decimal Inch) | 1.0040 |
| Maximum Bore Depth (Decimal Inch) | 1.0040 |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.0000 |
| Head Height (Decimal Inch) | 0.9100 |
| Head Length (Decimal Inch) | 1.0040 |
| Shank Length (Decimal Inch) | 3.9960 |
| Manufacturers Catalog Number | KGBAL12435 |
| Height to Shank Top (Decimal Inch) | 0.7500 |
| Complete Insert Compatibility | GBA43R/L 078R; GBA43R/L 094R; GBA43R/L 141N; GBA43R/L 142N; GBA43R/L 156MYN; GBA43R/L 156N; GBA43R/L 172N; GBA43R/L 178N; GBA43R/L 188N; GBA43R/L 350-010; GBA43R/L 350-030; GBA43R/L 400-010; GBA43R/L 400-040; GBA43R/L 430-040; GBA43R/L 450-040; GBA43R/L 4 |
