Iscar - PTGN, Left Hand Cut, 3/4" Shank Height x 3/4" Shank Width, Negative Rake Indexable Turning Toolholder - 4-1/2" OAL, Multiple Insert Compatibility, Series Heliturn LD
Item #: 50099548
Brand: Iscar
Model #: 3603473
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Left Hand |
| Toolholder Style | PTGN |
| Rake | Negative |
| Series | Heliturn LD |
| Shank Width (Decimal Inch) | 0.7500 |
| Shank Height (Decimal Inch) | 0.7500 |
| Overall Length (Decimal Inch) | 4.5000 |
| Insert Compatibility | TNGA 331; TNGA 331T; TNGA 332; TNGA 332E; TNGA 332T; TNGA 333; TNGA 333T; TNGA 432T; TNGA 434T; TNGG 330.5; TNGG 332; TNGG 333; TNGZ 321; TNGZ 331; TNGZ 431; TNMA 331; TNMA 331T; TNMA 332; TNMA 332T; TNMA 333; TNMA 334; TNMA 432; TNMA 433; TNMA 434; TNMG |
| Multi-Use Tool | No |
| Insert Holding Method | Lever Lock |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.0000 |
| Head Length (Decimal Inch) | 0.7800 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
