Iscar - GHD, External, Left Hand, 16.5mm Max Depth of Cut, 7 to 10mm Groove Width, Indexable Grooving Tool Holder - GI.., GPV, TIP Insert Compatibility, 25mm Shank Height, 25mm Shank Width, 150mm OAL, Through Coolant
Item #: 50098847
Brand: Iscar
Model #: 2802075
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Toolholder Type | NonFace Grooving |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.6496 |
| Maximum Depth of Cut (mm) | 16.50 |
| Minimum Groove Width (Decimal Inch) | 0.2756 |
| Minimum Groove Width (mm) | 7.00 |
| Maximum Groove Width (mm) | 10.00 |
| Maximum Groove Width (Decimal Inch) | 0.3937 |
| Overall Length (mm) | 150.00 |
| Overall Length (Decimal Inch) | 5.9055 |
| Toolholder Style | GHD |
| Insert Compatibility | GI..; GPV; TIP |
| Shank Height (mm) | 25.00 |
| Shank Height (Decimal Inch) | 0.9843 |
| Shank Width/Diameter (mm) | 25.00 |
| Shank Width/Diameter (Decimal Inch) | 0.9843 |
| Series | Cut Grip; JetHPLine |
| Through Coolant | Coolant Through |
| Multi-Use Tool | Yes |
| Multi-Use Application | Turning |
| Insert Holding Method | Self Clamp |
| Maximum Hole Depth (Decimal Inch) | 1.9685 |
| Back of Bar to Cutting Edge (Decimal Inch) | 21.8000 |
| Head Length (mm) | 50.00 |
| Head Length (Decimal Inch) | 1.9685 |
| Full Radius Insert | Yes |
| Shank Length (mm) | 100.00 |
| Shank Length (Decimal Inch) | 3.9370 |
| Complete Insert Compatibility | GIA 3.00K-0.40; GIA 4.00K-0.40; GIA 4.00K-0.80; GIA 5.00K-0.80; GIA 6.00K-0.80; GIF 3.48-0.20; GIF 3.56-0.20; GIF 3.74-0.20; GIF 3.98-0.20; GIF 4.00E-0.40; GIF 4.00E-0.60; GIF 4.00E-0.80; GIF 4.00E-2.00; GIF 4.23-0.10; GIF 4.45-0.15; GIF 4.78-0.55; GIF 4. |
