Square D - 4, 13 and 4X NEMA Rated, SPDT, 5 to 250 psi, Electromechanical Pressure and Level Switch - Adjustable Pressure, 125 VDC at 1.10 Amp, 1/2 Inch Connector, Screw Terminal, For Use with 9012G
Item #: 49749278
Brand: Square D
Model #: 9012GAW6H3Z16
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Pressure Switch Type | Electromechanical |
| NEMA Rating | 4; 13; 4X |
| Maximum Pressure Setting | 250 psi |
| Minimum Pressure Setting | 5 psi |
| Differential Pressure Type | Adjustable |
| Maximum Differential Pressure (psi) | 49.00 |
| Minimum Differential Pressure (psi) | 10.00 |
| Voltage | 125 VDC @ 1.10 A |
| Contact Form | SPDT |
| Connector Size (Decimal Inch) | 0.5000 |
| Terminal Type | Screw |
| Resistance Features | Shock Resistant; Vibration Resistant |
| For Use With | 9012G |
| Standards Met | CE; CSA C22.2 No. 14; CSA LR25490 Class 3211 03; IEC 58; IEC 68-2-6; RoHS Compliant; UL 50; UL 508; UL Listed File E12158 CCN NKPZ & CCN NTHT |
| Amperage | 1.10 @ 125 VDC |
