Parker - Metal Push-To-Connect Tube Fittings Type: Male Swivel Branch Tee Tube Outside Diameter (Inch): 1/4
Item #: 19281625
Brand: Parker
Model #: 165PW-8
Product Specifications
Metal Push-To-Connect Tube Fittings; Type: Male Swivel Branch Tee ; Tube Outside Diameter (Inch): 1/4 ; Maximum Working Pressure: 300.000 ; Connection Style: Push to Connect ; Connection Type: Tube to Male NPT ; Material: Nickel Plated Brass
| Type | Male Swivel Branch Tee |
| Tube Outside Diameter (Inch) | 1/4 |
| Maximum Working Pressure | 300.000 |
| Connection Style | Push to Connect |
| Connection Type | Tube to Male NPT |
| Material | Nickel Plated Brass |
| Thread Size | 3/8 |
| Thread Type | NPT |
| Hex Size (Inch) | 11/16 |
| O-Ring Material | Buna Nitrile |
| Minimum Work Temperature (F) | 0.000 |
| Maximum Work Temperature (F) | 200.000 |
| ForUseWith | Parker ParFlex 95FR MicroWeld Tubing |
| Special Item Information | UL94 V-0 Rated; PVDF UL94 V-0 Release Button |
