Supermill - Corner Radius & Corner Chamfer End Mills Mill Diameter (Inch): 1 Mill Diameter (Decimal Inch): 1.0000
Item #: 47376439
Brand: Supermill
Model #: SM3F1.0R
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
nACRo is a nanocomposite coating that is extremely wear and heat resistant. It is commonly used on steel, hardened steel, aluminum alloy and cast iron.
Product Specifications
Corner Radius & Corner Chamfer End Mills; Mill Diameter (Inch): 1 ; Mill Diameter (Decimal Inch): 1.0000 ; End Type: Corner Radius ; Corner Radius (Inch): 0.03 ; Number of Flutes: 3 ; Material: Solid Carbide
| Mill Diameter (Inch) | 1 |
| Mill Diameter (Decimal Inch) | 1.0000 |
| End Type | Corner Radius |
| Corner Radius (Inch) | 0.03 |
| Number of Flutes | 3 |
| Material | Solid Carbide |
| Finish/Coating | nACRo |
| Length of Cut (Inch) | 2 |
| Length of Cut (Decimal Inch) | 2.0000 |
| Shank Diameter (Inch) | 1 |
| Overall Length (Inch) | 4 |
| Cutting Direction | Right Hand |
| Helix Angle | 35 |
| Variable Index | No |
| Variable Helix | No |
| Material Grade | Micrograin |
| Single or Double End | Single |
| Centercutting | Yes |
| Series/List | SM3F |
| Chipbreaker | No |
