Sandvik Coromant - CTGP, Left Hand Cut, -1° Lead Angle, 3/4" Shank Height x 3/4" Shank Width, Positive Rake Indexable Turning Toolholder - 4-1/2" OAL, TPUN 160308 Insert Compatibility, Series T-Max S
Item #: 49447931
Brand: Sandvik Coromant
Model #: 5726253
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Left Hand |
| Toolholder Style | CTGP |
| Rake | Positive |
| Rake Angle | 6 |
| Series | T-Max S |
| Lead Angle | -1 |
| Shank Width (Inch) | 3/4 |
| Shank Width (Decimal Inch) | 0.7500 |
| Shank Height (Inch) | 3/4 |
| Shank Height (Decimal Inch) | 0.7500 |
| Overall Length (Inch) | 4-1/2 |
| Overall Length (Decimal Inch) | 4.5000 |
| Insert Compatibility | TPUN 160308 |
| Multi-Use Tool | No |
| Insert Holding Method | Clamp |
| Back of Bar to Cutting Edge (Inch) | 1-1/8 |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.1250 |
| Head Length (Decimal Inch) | 1.2000 |
| Toolholder Material | Steel |
