Electro Hardware - #8-32, 1-1/4" OAL, 1/4" Across Flats, Nylon Male/Female Hex Circuit Board Standoff
Item #: 95765285
Brand: Electro Hardware
Model #: 1447-M19F16-832
Features and Benefits
Circuit board standoffs with male/female threads have one externally threaded end and one internally threaded end. The female end accepts male fasteners or other standoffs.
Nylon is a lightweight, nonconductive material that is resistant to impact, wear and abrasion. It is ideal for electrical applications or where corrosion is a concern.
| Product Specifications | |
|---|---|
| Thread Type | Male/Female |
| Material | Nylon |
| System of Measurement | Inch |
| Body Shape | Hex |
| Overall Length (Inch) | 1-1/4 |
| Thread Style | Fully Threaded |
| Thread Size | #8-32 |
| Width Across Flats (Inch) | 1/4 |
| Finish/Coating | Uncoated |
| Body Length (Decimal Inch) | 0.8750 |
| Thread Length (Inch) | 3/8 |
| Thread Depth (Inch) | 0.4370 |
| Material Grade | 6/6 |
