Rotor Clip - 3/16" Groove Diam, 7/32" Shaft Diam, Zinc-Plated Spring Steel, E Style External Retaining Rings - 0.029" Groove Width, 0.015" Groove Depth, 0.025" Ring Thickness, Grade 1060-1090
Item #: 48348213
Brand: Rotor Clip
Model #: SE-21ST ZF
Exact Tooling IR#: 04
Features and Benefits
E-style external retaining rings snap into grooves from the side of a shaft. They are ideal for use on small-diameter shafts. E-style retaining rings are also referred to as radially installed or side-mount retaining rings.
Spring steel is a low-alloy, carbon steel with very high yield strength.
| Product Specifications | |
|---|---|
| Type | E Style |
| System of Measurement | Inch |
| Shaft Diameter (Inch) | 0.2190 |
| Shaft Diameter (Decimal Inch) | 0.2190 |
| Groove Diameter (Decimal Inch) | 0.1880 |
| Free Diameter (Decimal Inch) | 0.1850 |
| Free Outside Diameter (Decimal Inch) | 0.4370 |
| Military Specification | Does Not Meet Military Specifications |
| Material | Spring Steel |
| Finish/Coating | Zinc-Plated |
| Nominal Size (Inch) | 7/32 |
| Material Grade | 1060-1090 |
| Groove Width (Decimal Inch) | 0.0290 |
| Groove Depth (Decimal Inch) | 0.0150 |
| Ring Thickness (Decimal Inch) | 0.0250 |
| Groove Diameter Tolerance (Decimal Inch) | 0.0000 to 0.0020 |
