Rotor Clip - 1.35" Groove Diam, 1-7/16" Shaft Diam, Phosphate Spring Steel, Snap External Retaining Rings - 0.056" Groove Width, 0.044" Groove Depth, 0.05" Ring Thickness, Grade 1060-1090
Item #: 48348205
Brand: Rotor Clip
Model #: SH-143ST PA
Exact Tooling IR#: 04
Features and Benefits
Snap external retaining rings are pulled open and placed onto the shaft end. The ring is then released and springs onto the shaft s grooves.
Spring steel is a low-alloy, carbon steel with very high yield strength.
| Product Specifications | |
|---|---|
| Type | Snap |
| System of Measurement | Inch |
| Shaft Diameter (Inch) | 1.4380 |
| Shaft Diameter (Decimal Inch) | 1.4380 |
| Groove Diameter (Decimal Inch) | 1.3500 |
| Free Diameter (Decimal Inch) | 1.3330 |
| Free Outside Diameter (Decimal Inch) | 1.4560 |
| Military Specification | Does Not Meet Military Specifications |
| Material | Spring Steel |
| Finish/Coating | Phosphate |
| Nominal Size (Inch) | 1-7/16 |
| Material Grade | 1060-1090 |
| Groove Width (Decimal Inch) | 0.0560 |
| Groove Depth (Decimal Inch) | 0.0440 |
| Ring Thickness (Decimal Inch) | 0.0500 |
| Groove Diameter Tolerance (Decimal Inch) | -0.0040 to 0.0040 |
| Free Diameter Tolerance (Decimal Inch) | -0.015 to 0.010 |
