Rotor Clip - 14.3mm Groove Diam, 15mm Shaft Diam, Phosphate Spring Steel, Snap External Retaining Rings - 1.1mm Groove Width, 1mm Ring Thickness
Item #: 48348064
Brand: Rotor Clip
Model #: DSH-15ST PD
Exact Tooling IR#: 04
Features and Benefits
Snap external retaining rings are pulled open and placed onto the shaft end. The ring is then released and springs onto the shaft s grooves.
Spring steel is a low-alloy, carbon steel with very high yield strength.
| Product Specifications | |
|---|---|
| Type | Snap |
| System of Measurement | Metric |
| Shaft Diameter (mm) | 15.00 |
| Groove Diameter (mm) | 14.30 |
| Free Diameter (mm) | 13.80 |
| Free Outside Diameter (mm) | 13.80 |
| Military Specification | Does Not Meet Military Specifications |
| Material | Spring Steel |
| Finish/Coating | Phosphate |
| Nominal Size (mm) | 15.00 |
| Groove Width (mm) | 1.10 |
| Ring Thickness (mm) | 1.00 |
